EN3
www.afx-light.com
39 CHANNELS
CH Channel value Description
1 000-255 Total dimming
2 000-255 Three in one stroboscopic
3 000-255 The rst mock exam is the rst mock exam. Three in one mode (see: six,
three in one mode).
4 000-255 Three in the rst mock exam speed
5 000-255 Section 1 three in one red light bead linear dimming
6 000-255 Section 1 three in one green light bead linear dimming
7 000-255 Section 1 three in one blue light bead linear dimming
…
26 000-255 Section 8 three in one red light bead linear dimming
27 000-255 Section 8 three in one green light bead linear dimming
28 000-255 Segment 8 three in one blue light bead linear dimming
29 000-255 White strobe
30 000-255 White light mode (see VI. white light mode effect for details)
31 000-255 White light mode speed
32 000-255 Section 1 white light bulb linear dimming
33 000-255 Linear dimming of section 2 white light bulb
34 000-255 Section 3 white light bulb linear dimming
35 000-255 Section 4 white light bulb linear dimming
36 000-255 Section 5 white light bulb linear dimming
37 000-255 Section 6 white light bulb linear dimming
38 000-255 Section 7 white light bulb linear dimming
39 000-255 Section 8 white light bulb linear dimming
RGB MODE EFFECTS / MODES D'EFFETS RGB
Channel
value
Mode
code
Effect
0-2 0 No effect
3-5 1 R all red light beads are on.
6-8 2 G green light beads are all on.
9-11 3 B the blue light beads are all on.
12-14 4 RG red and green dyeing lights are all on.
15-17 5 RB red and blue staining lights are all on.
18-20 6 GB green and blue staining lights are all on.
21-23 7 RGB red, green and blue staining lights are all on.
24-26 8 Comprehensive mode code 1-7 cycle.
27-29 9 Gradual change
30-32 10 Pulse change
33-35 11 A red light bead running horse.
36-38 12 A green light bead running horse.
39-41 13 A blue light bead running horse.
