of xtures that the data link can support.
Important: Fixtures on a serial/data link must be daisy chained in one single line.
DATA CABLING
To link xtures together you must use data cables. If you choose to create your own cable, please
use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DMX CONNECTOR CONFIGURATION
Termination reduces signal errors. To avoid signal transmission problems and interference, it is
always advisable to connect a DMX signal terminator.
INSTALLATION (FIG.3)
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is rmly
xed to avoid vibration and slipping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety rope. Never stand directly below the device when mounting, removing or servicing the x-
ture. This xture may be mounted in any position provided there is adequate room for ventilation.
The LED moving head provides a unique mounting bracket assembly that integrates the bottom of
the base, the included ‘omega bracket’ and the safety cable rigging point in one unit (see illustra-
tion).When mounting this xture on a truss, be sure to use an appropriate clamp with the included
omega bracket using a M10 screw tted through the center hole of the ‘omega bracket’. As an add-
ed safety measure, be sure to attach at least one properly rated safety cable to the xture using
one of the safety cable rigging points integrated in the base assembly.
POWER LINK
Connect an IEC cable from the POWER OUT connector of the 1st unit to the POWER IN connector of
the second unit, etc.
CONTROL PANEL (FIG. 2)
To access the main menu press the MENU button. Press the UP or DOWN buttons until you reach
function you wish to change. When you reach the function you wish to change, press the ENTER
button. When a function is selected, use the UP or DOWN buttons to change the function settings.
Once your changes are made, press the ENTER button.
Tip: Press UP & DOWN buttons at the same time for 3 seconds. The display will reverse.
FUNCTION MENU
MENU DESCRIPTION
Operating
Mode
DMX address A001-AXXX DMX address setting
Channel Mode
CH17 17 channel mode
CH15 15 channel mode
CH19 19 channel mode
Auto run
Internal program 1-9
Auto runState: Master/Alone
Auto run (On/off)
Music control
Internal program 1-9
Sound controlState: Master/Alone
Music run (On/off)
