EN 6
© Copyright LOTRONIC 2022
LAMP REPLACEMENT
IMPORTANT: Disconnect the unit from the mains prior to opening the lamp compartment.
Don’t touch the lamp with bare hands. If the lamp is hot, please wait at least 20 minutes to let it
cool down. Fasten the head with the Tilt lock in 60° position.
Remove the 2 screws on the rear panel
via a cross-headed screwdriver and re-
move the cover.
Keep the lamp holder in place with one
hand and pull out the wire and the lamp
with the other hand.
Once you have removed the lamp, clean
the inside part of the lens to get a bright-
er light output.
Push in the new lamp, place the wire inside the compartment and close the compartment with the
2 screws.
OPERATION
CONTROL PANEL
The LCD display shows you all information about moving head control
The wheel is used to select all menus and validate your settings.
Control wheel: turn right, left and press
CW rotation: increases the value
CCW rotation: decreases the value
MENU
Main
Menu
Sub-menu
1
Submenu
2
Function
SET
Function description
DMX
Address
001-512 Setting of DMX address
Display
Disp Flip
OFF Normal display
ON Reversed display by 180°
Disp Dim 0-100% Brightness
Backlight
1 min Backlight closes after a delay of 60 sec.
2 min Backlight closes after a delay of 120 sec.
3 min Backlight closes after a delay of 180 sec.
ON Backlight stays always on
Menuback
1 min Back to main menu after a delay of 60 sec.
2 min Back to main menu after a delay of 120 sec.
3 min Back to main menu after a delay of 180 sec.
DMX
Flash
ON Backlight is ashing when no DMX signal is received
OFF
Backlight doesn’t ash when no DMX signal is re-
ceived
Return
▲
Return
