EN 10

LUMEN

Distance 5m 23m

Illumination 81600 20200 11060 980

Spot size Ø 0.09 Ø 0.33m zoom Ø 0.40m Ø 1.60m zoom

DIMENSIONS

DMX CHANNEL CHART: SEE END OF MANUAL

THE FOLLOWING POINTS HAVE TO BE CONSIDERED DURING THE INSPECTION:

All screws for installing the devices or parts of the device have to be tightly connected and must

not be corroded.

There must not be any deformations on the housing, glass pane, xations and installation spots.

The electric power supply cables must not show any damage, material fatigue or sediments. Fur-

ther instructions depending on the installation spot and usage have to be adhered to by a skilled

installer and any safety problems have to be removed.

We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use

alcohol or solvents.

CAUTION: Disconnect from mains before starting maintenance operation!

CLEANING AND USING FREQUENCY OF PRODUCT

Please make sure that the light is power off before dismantling or maintaining, it’s very important

to keep the light clean. Frequent cleaning will ensure maximum brightness output, but also prolong

the life time. It’s suggested to use the high quality, professional glass detergent and soft cloth to

clean the light. It’s not allowed to use alcohol or chemical solvent. The inner part of the light should

be cleaned by vacuum cleaner at least once a year. When the light doesn’t work, please check if the

fuse is burnt out or not. If it is, the same fuse should be replaced, nd out the faulty and restart the

light. But please note the repair must be handled by professional.

SPECIFICATIONS

Lamp power .............................................................................................................................................. 150W

Lamp model .......................................................................................................................................BORYLI 3R

Pan ............................................................................................................................................................... 540°

Tilt ................................................................................................................................................................ 270°

Power supply ................................................................................................................... 220-240V~ 50/60Hz

Consumption ............................................................................................................................................. 230W

Dimensions .......................................................................................................................333 x 323 x 540mm

Weight ......................................................................................................................................................16.5kg

IMPORTANT NOTE: Electric products must not be put into household waste. Please bring them to a recycling centre. Ask your local

authorities or your dealer about the way to proceed.
