EN 6

• Slide the battery compartment open.

• Remove the old battery and install the new one (CR2025) with the plus (+) symbol facing up.

• Gently slide the battery compartment closed. It locks automatically.

RECOMMENDATIONS FOR BATTERIES

This symbol indicates that used batteries should not be disposed of with household waste but deposed correctly in accordance with

your local regulations..

Batteries shall not be exposed to excessive heat such as sunshine, re or the like.

When the internal batteries are not to be used, remove them to avoid damage caused by battery leakage or corrosion.

ATTENTION: Danger of explosion if battery is incorrectly placed. Only replace by the same or equivalent type.

WARNING :Do not swallow the battery. Danger of chemical burns. Keep new and old batteries out of the reach of children.

If the battery compartment doesn’t close properly, stop using the product and keep it out of the reach of children.

If you are in doubt whether the batteries have been swallowed or introduced into any other part of the body, contact immediately a doctor.

REMOTE CONTROL

NOTE: PLEASE SET THE UNIT TO MODE -> ADDR, OTHERWISE

THE REMOTE CONTROL WILL NOT WORK

1. BRIGHTNESS & SPEED adjustment: Press

or to set the

brightness and speed in programme mode

2. ON/OFF of the LEDs.

3. SELECT LED:

R: LED 1

G: LED 2

B: LED 3

W: LED 4

4. COLOUR BUTTONS: Press one of the 12 colour buttons to select a

built-in programme.

PHOTOMETRIC DIAGRAM

()

13100

400

600

diameter(m) Ø0.6 Ø2.3

Ø3.6

FIXTURE CLEANING

The cleaning of internal and external optical lenses and/or mir-

rors must be carried out periodically to optimize light output.

Cleaning frequency depends on the environment in which the

xture

operates: damp, smoky or particularly dirty surrounding can

cause greater accumulation of dirt on the unit’s optics.

a. Clean with soft cloth using normal glass cleaning uid.

b. Always dry the parts carefully.

SPECIFICATIONS

Power supply ..................................................................................................................... 100-240V~50/60Hz

Consumption ............................................................................................................................................. 280W

Light source .............................................................................................................................. 4 x 50W UV LED

UV wave length ................................................................................................................................ 390-400nm

Dimensions ........................................................................................................................ 299 x 155 x 279mm

Weight ....................................................................................................................................................... 4.75kg

IMPORTANT NOTE: Electric products must not be put into household waste. Please bring them to a recycling centre.

Ask your local authorities or your dealer about the way to proceed.
