EN3
www.afx-light.com
• The max. ambient temperature (Ta) is 40°C. Don’t operate the xture at higher temperatures.
• In the event of a serious operating problem, stop using the unit immediately. Never try to repair
the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction.
Please contact the nearest authorized technical assistance center. Always use the same type of
spare parts.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on as sensitive persons may suffer an
epileptic shock (especially meant for epileptics)!.
• The product is for decorative purposes only and not suitable as a household room illumination.
• If the external exible cable or cord of this luminaire is damaged, it shall be exclusively replaced
by the manufacturer or his service agent or a similar qualied person in order to avoid a hazard.
• The lenses, housing or ultraviolet lter must be replaced if they are visibly damaged.
• The light source of this device is not replaceable. If it is defective, the entire unit must be discard-
ed.
DISCONNECT DEVICE
Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
FEATURES
• 13 / 44 DMX channels
• 9x 12W RGBW LED
• Extra long life CREE LEDs (>50,000 h)
• 3 x 3 zones
• Narrow beams
• DMX, stand-alone, master-slave and show modes
• Built-in music controlled programs
• Pulse & Strobe effects
• Electronic dimmer 0-100%
• Suitable for wall, truss or oor mounting
INSTALLATION
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is rmly
xed to avoid vibration and slipping while operating. Always ensure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate
safety rope.
Never stand directly below the device when mounting,
removing or servicing the xture.
ORIENTATION
This xture may be mounted in any position provided
there is adequate room for ventilation.
RIGGING
The LED moving head provides a unique mounting
bracket assembly that integrates the bottom of the
base, the included ‘omega bracket’ and the safety cable
rigging point in one unit (see illustration).When mount-
ing this xture on a truss, be sure to use an appropriate
clamp with the included omega bracket using a M10 screw tted through the center hole of the
‘omega bracket’. As an added safety measure, be sure to attach at least one properly rated safety
cable to the xture using one of the safety cable rigging points integrated in the base assembly.
