11. TECHNICAL DATA
11.1 Rating plate
Model TR84IT00FB PNC 949 598 295 00
Typ 62 D6A 06 AA 220 - 240 V / 400 V 2N, 50 - 60 Hz
Induction 7.2 kW Made in: Germany
Ser.Nr. ................. 7.2 kW
AEG
11.2 Cooking zones specification
Induction cooking sur‐
face
Nominal power
(maximum heat set‐
ting) [W]
PowerBoost [W] PowerBoost maximum
duration [min]
Single triangle 1150 1600 10
Standard cooking zone 2000 3000 10
Centre zone 4200 - -
Vertical zone 3200 - -
Horizontal left zone 4100 - -
Horizontal right zone 3200 - -
The power of the cooking zones can be different from the data in the table. It changes with the
material and dimensions of the cookware.
Cookware sizes
Bridge mode Cookware dimension (mini‐
mum)
Cookware dimension (maxi‐
mum)
Single triangle 100 mm 160 mm
Standard cooking zone 160 mm 210 mm
Centre zone 240 mm 350 mm
Vertical zone The area of 3 single triangles The area of 4 single triangles
Horizontal zone The area of 3 single triangles The area of 4 single triangles
For more information on the recommended cookware dimensions, refer to "Induction cooking
surface" in "Daily use".
12. ENERGY EFFICIENCY
24 ENGLISH
