10.2 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
PowerBoost [W] PowerBoost
maximum dura‐
tion [min]
Cookware diame‐
ter [mm]
Left front 2300 3700 10 180 - 210
Left rear 1800 2800 10 145 - 180
Right front 1400 2500 4 125 - 145
Right rear 2300 3200 10 145 - 265
The power of the cooking zones can be
different in some small range from the data in
the table. It changes with the material and
dimensions of the cookware.
For optimal heat transfer and cooking results
use cookware with bottom diameter similar to
the size of the cooking zone (i.e. the
maximum cookware diameter value in the
table). Do not use cookware larger than the
diameter of the cooking zone.
11. ENERGY EFFICIENCY
11.1 Product Information according to EU Ecodesign Regulation
Model identification TO64IC0BIT
Type of hob Built-In Hob
Number of cooking zones 4
Heating technology Induction
Diameter of circular cooking zones (Ø) Left front
Left rear
Right front
21.0 cm
18.0 cm
14.5 cm
Length (L) and width (W) of non circular cooking
zone
Right rear L 26.5 cm
W 17.0 cm
Energy consumption per cooking zone (EC electric
cooking)
Left front
Left rear
Right front
Right rear
178.4 Wh/kg
184.9 Wh/kg
183.2 Wh/kg
184.9 Wh/kg
Energy consumption of the hob (EC electric hob) 182.9 Wh/kg
IEC / EN 60350-2 - Household electric
cooking appliances - Part 2: Hobs - Methods
for measuring performance.
The energy measurements referring to the
cooking area are identified by the markings of
the respective cooking zones.
11.2 Energy saving
You can save energy during everyday
cooking if you follow the hints below.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on the
cookware.
ENGLISH 21
