3. Press to start the timer or wait 3
seconds. The timer begins to count down.
To change the time: select the cooking zone
with and press or .
To deactivate the function: select the
cooking zone with and press . The
remaining time counts back to 00.
The timer finishes counting down, a signal
sounds and 00 blinks. The cooking zone
deactivates. Press any symbol to stop the
signal and blinking.
Minute Minder
You can use this function when the hob is
activated but the cooking zones do not
operate. The heat setting shows 00.
1. Press
.
2. Press or to set the time.
The timer finishes counting down, a signal
sounds and 00 blinks. Press any symbol to
stop the signal and blinking.
To deactivate the function: press and
. The remaining time counts back to 00.
6.8 Power management
If multiple zones are active and the
consumed power exceeds the limitation of the
power supply, this function divides the
available power between all cooking zones.
The hob controls heat settings to protect the
fuses of the house installation.
• If the hob reaches the limit of maximum
available power (refer to the rating plate),
the power of the cooking zones will be
automatically reduced.
• The heat setting of the cooking zone
selected first is always prioritised. The
remaining power will be divided between
the other cooking zones according to the
order of selection.
• For cooking zones that have a reduced
power, the control bar blinks and shows
the maximum possible heat settings.
• Wait until the display stops flashing or
reduce the heat setting of the cooking
zone selected last. The cooking zones will
continue operating with the reduced heat
setting. Change the heat settings of the
cooking zones manually, if necessary.
• The hood extractor is always available as
an electrical load.
6.9 Hood functions
WARNING!
Refer to Safety chapters.
Manual mode
The hood can operate alongside the hob
during the cooking session, as well as while
the hob is switched off.
1. Press to activate the hood.
A signal sounds and indicators above the
symbol appear.
2. Adjust the fan speed setting as needed
by pressing the symbol. The indicators
change to reflect the current fan speed.
3. To deactivate the hood, press
repeatedly until the indicators above the
symbol disappear.
AUTO
The function automatically adjusts the fan
speed level based on the temperature of the
cooking zone. The function is usually
activated by default.
AUTO mode offers four fan speed options:
H1-H4 (low to intense). H4 is set by default.
You can change the mode in the settings.
Refer to "Menu structure".
You can activate the function while the hob is
on and none of the cooking zones are active,
or at any point during the cooking session.
If you activate the function while the hob
is off, none of the cooking zones operate
and there is no residual heat visible on
the control panel, the function will switch
off by itself after a few seconds.
1. Press and hold to activate the hob.
2. If the function is not on by default, press
AUTO to activate it.
14 ENGLISH
