1. Open the door fully and hold both hinges.
2. Lift and pull the latches until they click.
3. Close the oven door halfway to the first
opening position. Then lift and pull to
remove the door from its seat.
4. Put the door on a soft cloth on a stable
surface.
5. Hold the door trim on the top edge of
the door at the two sides and push
inwards to release the clip seal.
1
2
B
6. Pull the door trim to the front to remove it.
7. Hold the door glass panels by their top
edge and carefully pull them out one by
one. Start from the top panel. Make sure
the glass slides out of the supports
completely.
8. Clean the glass panels with water and
soap. Dry the glass panels carefully. Do
not clean the glass panels in the
dishwasher.
9. After cleaning, install the glass panels
and the oven door.
If the door is installed correctly, you will hear
a click when closing the latches.
Make sure that you put the glass panels (
and ) back in the correct sequence. Check
for the symbol / printing on the side of the
glass panel. Each of the glass panels looks
different to make the disassembly and
assembly easier.
When installed correctly, the door trim clicks.
A B
Make sure that you install the middle glass
panel in the seats correctly.
A
B
ENGLISH 21
