13ENGLISH
5.
INSTALLATION INSTRUCTIONS
5.1
Exhausting hot air
In the Cool Mode, the unit must be placed
close to a window or opening so that the
warm exhaust air can be ducted outside.
Firstpositionunitonaatoorandmake
sure there's a minimum of 50cm clearance
around the unit, and that it is close to a
power socket.
1.
Extend either side of the hose (Fig. 1)
and screw the hose to adaptor A (Fig. 2).
2.
Extend the other side of the hose and
screw it to adaptor B (Fig. 3).
4.
Open the window and place Adapter B
through the gap. (Fig. 5)
3.
Lock the adaptor A into the unit. (Fig. 4)
The hose can be extended from its
original length of 38cm up to 150cm,
but it is best to keep the length to a
minimumforeciency.Alsomake
sure that the hose does not have any
sharp bends or sags. (Fig. 6)
Note:
If need to install the window kit, please
refer to the
Window Kit Instruction Manual
.
Extend the side of hose
(Fig. 1)
1
A
2
(Fig. 2)
2
1
B
(Fig. 3)
(Fig. 4)
Lock
B
(Fig. 5)
(Fig. 6)
