7
V3.2
The Drawer Fridge/Freezer is supplied with an Anderson style power connector, the power supply to this
connector must come directly from the vehicle battery. The following cables with suitable sections and lengths
must be used (see below table).
All direct connections to the battery must be adequately fused via a 15 Amp fuse which also helps reduce the
risk of voltage drop to the fridge. The fuse shall be located as close as reasonably possible to the battery or
power source.
6. WIRING
Cable Selection Max Length Cable (Metres)
Minimum Size 12V 24V
2.5mm2 (AWG 13) 2 (8FT) 5 (16FT)
4mm2 (AWG 11) 4 (13 FT) 8 (26 FT)
6mm2 (AWG 9) 6 (20 FT) 12 (40 FT)
1. Place the refrigerator on a dry, flat, protected surface, away from corners. Do not use the refrigerator in
uncovered, outdoor areas or areas exposed to the elements.
2. The refrigerator requires good ventilation. Leave a space of at least 5 cm across all its sides.
3. Avoid placing the refrigerator near to a heat source, for example a cooker, radiator, or exposing it to
direct sunlight.
4. Do not place ice or liquids which are not sealed in containers within the refrigerator.
5. Do not place hot products within the refrigerator.
6. Your Drawer Fridge/Freezer can be permanently installed using the included pre-installed feet or the
included mounting brackets. A minimum gap of 50mm on each side and an additional 100mm at the
rear should be accounted for. The gap helps all side of the Drawer Fridge/Freezer breathe for higher
efficiency, especially the rear where most of the heat is generated.
7. INSTALLATION
If installed in a caravan or similar environment, large vents should be installed to allow air to vent to the outside
environment. A lower vent to intake cool air and a higher vent for exhaust of warm air. The vents should be at
least 200cm
2
in size.
8. EFFICIENT OPERATION
