WISE-750 User Manual 6
2.1 Unpacking
After receiving your WISE-750 package, inspect its contents first.
The package should contain the following items:
WISE-750 Module
Terminal blocks: 1 x 2-pin, 1 x 12-pin
4 x 4-pin connectors
1 x DIN Rail kit with 3 x screws
(Optional) 2 x PCL-M10-3E sensor
Startup Manual
The WISE-750 module harbors certain electronic components vulnerable to electro-
static discharge (ESD). ESD could easily damage the integrated circuits and certain
components if preventive measures are not carefully paid attention to.
Before removing the module from the anti-static box, you should take following pre-
cautions to prevent ESD damage:
Touch a metal part of your computer chassis with your hand to discharge static
electricity accumulated on your body. Or use a grounding strap.
After taking out the module, you should first inspect the module for any possible signs
of external damage (loose or damaged components, etc.). If the module is visibly
damaged, please notify our service department or the local sales representative
immediately. Avoid installing a damaged module into your system. Also, pay extra
caution to the following aspects to ensure proper installation:
Avoid physical contact with materials that could hold static electricity such as
plastic, vinyl and Styrofoam.
Whenever you handle the module, grasp it only by its edges. DO NOT TOUCH
the exposed metal pins of the connector or the electronic components.
2.2 Configuration with WISE-750 Utility
To start using the WISE-750, you need to download and install the utility first. The util-
ity can be downloaded from Advantech support portal (https://support.advant-
ech.com/support/new_default.aspx). After the installation, you can find the program
under Start/Advantech Automation/WISE750/WISE-750 Utility.
Device Connection
1. The WISE-750 is an Ethernet device with default IP 10.0.0.1. To connect to the
device, you should set your NIC IP to identical network section 10.0.0.x with
sub-net mask setting 255.255.255.0. Or, any other configuration that could suc-
cessfully recognize the IP 10.0.0.1 is also fine.
2. Connect the Ethernet cable to WISE-750(suggest to be CAT 5e or above
grade).
3. Plug the power and you’ll see the power lamp lights up(10~30VDC power sup-
ply with 6W capability would be fine).
4. Start the utility.
Note! Keep the anti-static bag for future use. You may need the original pack-
age to store the module if you have to remove the module from the PC
or transport it elsewhere.
