47 WISE-4471 User Manual
Appendix A iSensing MQTT
A.1 iSensing MQTT Format for publishing
A.1.1 Topic Format: Advantech/IMEI/data
A.1.2 Payload Format
Field Description
Advantech Vendor of WISE Series
MAC (IMEI) MAC address or IMEI of WISE Series
data Topic for query the data of WISE Series
Field Abbreviation Description
Sequence
Number
s
Sequence number that updates each time a sensor reading
is made
0~9, 0~9, …
Time Stamp t
ISO 8601 timestamp of the UTC time when the sensor
reading was made
Quality q
Quality of the sensor reading
192: The value is good. There are no special conditions.
Configuration
Change
c
Configuration change affecting the reading (e.g., scaling,
calibration)
0~9, 0~9, …
Digital Input di
Digital Input Mode
true/false
Counter
0~4294967295
Frequency Mode
0~30000 (default unit: 0.1Hz),
0~300000 (default unit: 0.01Hz)
Digital Output do
Digital Output:
true/false
Analog Input ai
Engineering value of analog input:
-10000.000~10000.000 (unit: mV)
-20.000~20.000 (unit: mA)
Temperature
Sensor
temp
Temperature engineering data, the value is floating type.
Unit: According range code
For example,
999.120 -> 999.12 °C
-3.220 -> -3.22 °C
Temperature
Range Code
temprc
4096: Temperature (°C)
4097: Temperature (°F)
4098: Temperature (K)
Humidity Sen-
sor
rh
Humidity engineering data, the value is floating type.
Unit: According range code
Humidity
Range Code
rhrc 4128: Humiidty (%)
RS-485 p1v06r0012x05
p1: Port number
v01: Slave ID
s: Coil (r: Register)
00b1: Modbus/RTU address
x02: Mapping channel
