2. Configuration Application of SMPTE2110
VEGA3311 SDK supports series API to setup SMPTE2100 in VEGA3311 card. User can use
command vega3311_voip2110_config to set almost setting in SMPTE2110. This document use SDK
vega_bqb_release_1_4_3_17677 to explain how to use configuration application to setup
SMPTE2110 in VEGA3311 card.
Now user can run command “vega3311_voip2110_config” to get help of SMPTE2110 configuration
application.
eager@test-desktop:~$ vega3311_voip2110_config
VEGA3311 VOIP2110 utility
vega3311_voip2110_config list <card id#(ID start from 0)> <channel id(0~3)>
List all VOIP info for the all stream.
vega3311_voip2110_config set_eth_parm <card id#(ID start from 0)> <eth id(0~1)>
<status(0:disable 1:enable)> <IP addr(0.0.0.0~255.255.255.255)> <mask
addr(0.0.0.0~255.255.255.255)> <gateway addr(0.0.0.0~255.255.255.255)> <mac
addr(factory-setting:0:0:0:0:0:0 user-setting:0:0:0:0:0:1~ff:ff:ff:ff:ff:ff)>
Set network parameter for the Ethernet interface.
vega3311_voip2110_config get_eth_parm <card id#(ID start from 0)>
Get network parameter for all Ethernet interface.
vega3311_voip2110_config get_link_status <card id#(ID start from 0)> <eth id(0~1)>
Get link status by the Ethernet interface.
vega3311_voip2110_config set_ptp_parm <card id#(ID start from 0)> <priority1 value(0~255)>
<priority2 value(0~255)> <domain number(0~127)> <announce interval(range:-3~1)> <delay
mechanism(0:AUTO 1:E2E 2:P2P)> <hybrid E2E(0:disable 1:enable)> <Quality of service(0~255)>
Set parameter for the PTP.
vega3311_voip2110_config get_ptp_parm <card id#(ID start from 0)>
Get parameter by the PTP.
vega3311_voip2110_config get_lock_state <card id#(ID start from 0)> <channel id(0~3)>
Get lock state of PTP daemon & in-system PLLs.
vega3311_voip2110_config set_stream_parm <card id#(ID start from 0)> <eth id(0~1)> <channel
id(0~3)> <stream id(20:video 30:audio0 31:audio1 40:anc)> <transport type(U:UDP,R:RTP,T:RTCP)>
<src_ip_addr(0.0.0.0~255.255.255.255)> <src_port(0~65535)>
<dst_ip_addr(0.0.0.0~255.255.255.255)> <dst_port(0~65535)> <RTP payload type(1~127)>
<source-IP-option(0:disable 1:enable)> <destination-IP-option(0:disable 1:enable)>
<source-port-option(0:disable 1:enable)> <destination-port-option(0:disable 1:enable)>
Set VOIP parameter for the stream.
vega3311_voip2110_config get_stream_parm <card id#(ID start from 0)> <channel id(0~3)> <stream
