UTC-510/515/520/532/542 User Manual 2
1.1 Introduction
Advantech’s UTC-500 series products are 10.1”, 15.6”, 21.5”, 32”, and 42.5” fanless,
low-power, all-in-one touch panel computers suitable for use as control room comput-
ing devices, production line industrial digital signage, showroom interactive signage,
self-service kiosks, and public service terminals, as well as to support diverse digital
retail, hospitality, healthcare, education, entertainment, and information processing
applications. Featuring a protective enclosure, advanced touchscreen technology,
wireless capabilities, and rich I/O, the high-performance UTC series can also be inte-
grated with a wide range of optional peripherals and accessories according to spe-
cific application requirements.
1.2 Specifications
1.2.1 UTC-510
Processor
System
CPU
Intel® Atom™
E3825
(UTC-510D)
Intel® Celeron®
J1900
(UTC-510D)
Intel® Celeron®
N3350
(UTC-510G)
Intel® Pen-
tium® N4200
(UTC-510G)
Base Fre-
quency
1.33 GHz (dual-
core)
2 GHz (quad-
core)
1.10 GHz (dual-
core)
1.10 GHz (dual-
core)
Cache L2 cache 1 MB L2 cache 2 MB L2 cache 2 MB L2 cache 2 MB
Memory
1 x 204 pin SO-
DIMM DDR3L
1066 MHz up to 8
GB
1 x 204 pin SO-
DIMM DDR3L
1333 MHz up to
8 GB
1 x 204 pin SO-DIMM DDR3L
1866 MHz up to 8 GB
HDD 1 x 2.5 internal SATA HDD bay
Network (LAN) 1 x Gigabit Ethernet ports (Supports Wake on LAN)
I/O ports
2 x RS-232 COM (COM1 RS-422/
485 supported)*
1 x USB 2.0 / 1 x USB 3.0 / 2 x USB
2.0 (optional)*
1 x Gigabit Ethernet (RJ-45)
1 x VGA
Audio Line-out x 1, Mic-in x 1
2 x RS-232 COM (COM1 RS-422/
485 supported)*
2 x USB 3.0 / 2 x USB 2.0
(optional)*
1 x Gigabit Ethernet (RJ-45)
1 x VGA
Audio Line-out x 1, Mic-in x 1
Stereo
Speaker
1 x 2W
Bus Expansion
1 x Half-size mini PCIe
1 x Half-size mSATA
1 Full size MiniPCIe
1 Half size mSATA
Mounting VESA 75 x 75 mm
Dimensions
(W x H x D)
265.40 x 182.40 x 39.55 mm
Weight 1.80 kg (3.97 lb)
OS Support
WES7P 32/64bit
WES7E 32bit
Windows Pro Embedded 7 Pro 32/
64bit
WE8S 32bit
Windows Embedded 8.1 Industry
Pro 64bit
Win 10 IoT Enterprise 64bit
Linux Ubuntu 16.04
Android 4.4
Window 10 IoT Enterprise
Linux Ubuntu 16.04
Android 6.0
