17 USB-4751/4751L User Manual
Appendix A Specifications
A.4 General-Purpose Counter
A.5 General Specifications
Channels 2
Resolution 32-bits
Input Type 5 V TTL
Input Logic Value
Logic High 2.0 V min.
Logic Low 0.8 V max.
Working Voltage -0.25 V ~ 5.25 V
Input Protection
Voltage
-0.5 V ~ 6.5 V
Pull-Up Resistor 10 kΩ
Output Type 5 V TTL
Output Logic Value
Logic High 3.8 V min. @ 12 mA source/5.2 V max.
Logic Low 0.5 V max. @ 12 mA sink
Event Counting
Input
Frequency
10 MHz max.
Measurement Type Instant
Frequency
Measurement
Input Frequency 10 MHz max.
Accuracy ±0.1%
Measurement Type Instant
Counter Output
Function
Timer/pulse or pulse width modulation
Output Frequency 10 MHz max.
Accuracy 50 ppm
I/O Connector Type 50-pin box header x 2, 10-pin screw terminal × 1
Dimensions
132 x 80 x 32 mm
3
(5.2 x 3.2 x 1.3 in
3
)
Power Consumption 500 mW typ./2500 mW max.
Power Supply Output +5 V: 100 mA max.
Temperature
Operation 0 ~ 60° C (32 ~140° F)
Storage -20 ~ 70° C (-4 ~ 158° F)
Relative Humidity
Operation 10% to 90% RH, non-condensing
Storage 5% to 95% RH, non-condensing
