USB-4716 User Manual 16
A.1 Analog Input
A.2 Analog Output
Channels 16-ch single-ended/ 8-ch differential
Resolution 16 bits FIFO Size 1024 Samples
Sampling Rate 200 kS/s
Input Range and
Gain List
Gain 0.5 1 2 4 8
Gain Code 4 0 1 2 3
Bipolar (V) ±10 ±5 ±2.5 ±1.25 ±0.625
Unipolar (V) N/A 0~10 0~5 0~2.5 0~1.25
Drift
Gain 0.5 1 2 4 8
Zero (µV/° C) ±30
Gain (ppm/° C) 30 30 30 30 30
Small Signal
Bandwidth for
PGA
Gain 0.5 1 2 4 8
Bandwidth (MHz) 1.1 1.1 1.1 1.1 1.1
Input Protection 30 V max.
Input Impedance 1GW
Input Comm. Mode Voltage 11V
Accuracy
DC
INLE 1LSB
DNLE 3LSB
Gain 0.5 1 2 4 8
Gain Error (% of FSR) 0.015 0.03 0.03 0.05 0.1
AC
SINAD 83 dB
THD -88 dB
ENOB 13.5 bit
Channels 2
Resolution 16 bits FIFO Size N/A
Throughput 2 kHz
Operating Mode Single output
Output Range 0~5, 0~10, ±5, ±10 V
Accuracy DC
INLE ±2LSB
DNLE ±1LSB
Dynamic Performance
Slew Rate 0.125 V/µs
Settling Time 150 µs (to ±1/2 LSB of FSB)
Driving Capability 5 mA
Output Impedance 0.1W max.
