UNO-430-E1H User Manual 18
2.3.1.7 LED Indicators
There are five LEDs to indicate the status of the system power, HDD, LTE, WIFI and
PL programmable LED for user's configurations.
PWR(Power): Green means normal, orange means standby.
HDD: Flashing green means normal
LTE: Flashing green means normal
WIFI: Flashing yellow and green alternately means normal
PL: Programmable LED
23 NC 24 Mechanical notch E
25 Mechanical notch E 26 Mechanical notch E
27 Mechanical notch E 28 Mechanical notch E
29 Mechanical notch E 30 Mechanical notch E
31 Mechanical notch E 32 NC
33 GND 34 NC
35 USB_Z_SSTX1- 36 NC
37 USB_Z_SSTX1+ 38 NC
39 GND 40 NC
41 PCIE_A_X_RX3- 42 NC
43 PCIE_A_X_RX3+ 44 NC
45 GND 46 NC
47 PCIE_A_X_TX3- 48 NC
49 PCIE_A_X_TX3+ 50 M2_SYSCLK
51 GND 52 WIFI_PLTRST#
53 CLK_LAN1_PCIE 54 BT_ DISABLE_L
55 CLK_LAN1_PCIE+ 56 WLAN_DISABLE
57 GND 58 SMB_DATA
59 NC 60 SMB_CLK
61 NC 62 ALERT#
63 GND 64 NC
65 NC 66 NC
67 NC 68 NC
69 GND 70 NC
71 NC 72 +V3.3_MINI
73 NC 74 +V3.3_MINI
75 GND
Table 2.8: M.2 E Key Connector Pin Assignments
