3 UNO-3483G User Manual
Chapter 1 Overview
1.3 System Hardware
CPU: UNO-3483G: Intel Core® i7-3612QE (4M Cache, 2.10GHz)
Memory: 8G DDR3L SDRAM burn-in ((Non-ECC, DDR3/DDR3L with one
unbuffered SODIMM slot, up to 8G) Transcend/AQD-SD3L8GN16-SG 8GB
Indicators: LEDs for power, SATA, LAN (active status)
Storage: HDD: 2 × 2.5" SATA HDD/SSD bays, support SATA Gen3.0
Display: 1 ×VGA, 1 ×HDMI (support 2 independent displays) 1920 x 1200
Watchdog Timer: 256 levels time interval, programmable from 1 to 255 sec
Expansion Slots: UNO-3483G: 3 x Mini PCIe slots, 1x PCI slot or 1x PCIe slots
PCI Slot Power:
– 12 V @ 0.5 A
– -12 V @ 0.1 A
– 5 V @ 2 A
– 3.3 V @ 3 A
PCIe Slot Power:
– 12 V @ 2.1 A
– 3.3V @3 A
– 3.3 V aux @ 0.375 A
SATASlotPower:5V@0.7A
1.3.1 I/O Interfaces
LAN:
– 2 ×10/100/1000 Base-T RJ45 ports
– Support AMT (UNO-3483G) and wake on LAN
– Burn-in boot ROM in flash BIOS
USB Ports: 4 x USB Ports (2 x USB 2.0, 2 x USB 3.0 compliant )
1.3.2 Environment
Relative Humidity: 95% @40°C (Non-condensing)
Operating Temperature: -20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s
airflow
Shock Protection:
– IEC 60068-2-27
– Compact Flash: 50 G @ wall mount, half sine, 11 ms
– HDD: 20 G @ wall mount, half sine, 11 ms
Vibration Protection:
– IEC 60068-2-64 (Random 1 Oct./min, 1hr/axis.)
– Compact Flash: 2 Grms @ 5 ~ 500 Hz
– HDD: 0.3 Grms @ 5 ~ 500 Hz
1.3.3 Expansion Board (Optional)
Model: UNO-3483G
Optional Expansion Type: 1x PCI slot, or 1x PCIe slot
Note! Total power consumption combined on PCI and PCIe slots should be
less than 25 Watt.
