3 UNO-3272G User Manual
Chapter 1 Overview
1.3 Chipset
1.3.1 Functional specification
1.3.1.1 Processor
1.3.1.2 Chipset
1.3.1.3 Others
Processor Intel® Celeron® J1900 2.0GHz processor
Memory
Supports DDR3L 1333 MHz (without ECC)
SODIMM Socket
– 260-pin SODIMM socket*2 (up to 8 GB)
Processor
Graphics
Intel® HD Graphics for Intel Atom® Processor Z3700 Series
IO interface
– VGA: Supports resolutions up to 1920 x 1080 @ 60 Hz
(VGA connector: On-board D-SUB 15P)
– HDMI: Supports resolution up to 1920 x 1080 @ 60 Hz
(HDMI Connector: On-board HDMI 19P)
SATA Interface
1x SATA Revision 3.0 ports 2.5" HDD/SSD
1x NGFF M.2 M key, support 22x42
Support OS storage and boot
USB Interface
USB host interface for 3 x USB2.0 port /1 x USB3.0 port
Supports high-speed, full-speed, and low-speed capable
Supports legacy keyboard/mouse software
Power
Management
+10V~+36V DC Input Duel from 4pin plug connector
Power Connector: Plug-in block 4Px1
BIOS AMI 64Mb Flash BIOS via SPI
Serial Ports
4xUART on front panel
COM1/2: Support to RS-232/422/485 and setting mode by
BIOS and supports auto flow control (The data rate of each serial port up
to 115.2k)
COM 3/4: Support to RS-232 (The data rate of each serial port up to
115.2k)
Serial ports connector: D-SUB CON.9P
LAN
LAN1: Intel® i211AT; LAN2: Intel® i211AT
Compliant with IEEE 802.3az.
Supports 10/100/1000 Mbps
Supports Wake on LAN
Audio
Audio Codec: Realtek ALC888:
Compliant with HD Audio specifications
Supports to 16/20/24-bit DAC and 16/20/24-bit ADC resolution
1x audio Line-out phone jack on front panel
Battery backup BR2032 3V/190mAh
