UNO-2271G V3 User Manual 2
1.1 Introduction
Advantech's new UNO-2 series serves as modular Integrated Edge Computers, pro-
viding configuration flexibility for customers seeking to cost-effectively optimize their
services. The new integrated DIN-rail mounting kit is designed to be more rugged
and user-friendly, making it a perfect fit for control cabinets.
The new UNO-2271G V3 model features a rugged design with an industrial-grade
Intel® Atom® dual-core x7211RE processor, built-in 8GB LPDDR5, and 64GB
eMMC. It supports a wide temperature range (-20 to 60°C / -4 to 140°F) and offers
sufficient I/O, including 2 x LAN, 1 x USB 3.2 Gen 2, and 1 x USB Type-C (1.5A),
which supports DP, USB, and DP Alt Mode, plus 1 x HDMI and 1 x 2-pin terminal
block. It also supports 1 x M.2 B-key slot (PCIe x1 / SATA / USB 3.2) to enable
expansion.
An optional second-stack extension kit supports 2 x RS-232/422/485 and 1 x PoE+
(802.3at) or 1 x iDoor module, such as industrial Fieldbus, as well as additional I/O
and peripheral modules. This expandability makes Advantech’s UNO-2 series an
excellent choice for various industrial applications. Additionally, UNO-2’s flexible
expandability and control functions meet emerging demands for Industry 4.0.
1.2 Safety Precautions
Below are a few safety precautions for preventing injury when making connections. In
most cases, users can use a standard cable for connection.
Warning! Always disconnect the power cord from the chassis before manual han-
dling. Do not connect the chassis while the system power is on. A sud-
den rush of power can damage sensitive electronic components. Only
experienced electronics personnel should open the chassis.
Warning! Toujours à la terre pour éliminer toute charge d'électricité statique avant
toucher UNO-2271G V3. Appareils électroniques modernes sont très
sensibles à charges d'électricité statique. Utilisez un bracelet antista-
tique à tout moment. Placez tous composants électroniques sur une
surface antistatique ou dans un statique-sac blindé.
Caution! Always ground yourself to remove any static electric charge before
touching UNO-2271G V3. Modern electronic devices are very sensitive
to static electric charges. Use a grounding wrist strap at all times. Place
all electronic components on a static-dissipative surface or in a static
shielded bag.
Caution! Toujours débrancher le cordon d'alimentation de votre boîtier lorsque
vous êtes travailler. Ne branchez pas lorsque l'appareil est allumé. Un
afflux soudain de puissance peut endommager les composants électro-
niques sensibles. Seulement connu personnel de l'électronique
devraient ouvrir le châssis.
