TREK-773 User Manual 4
– 1 x J1708 with high density connector
– 1 x built-in 2.0w speaker and 1 x built-in microphone in front panel
– 1 x Line-in/Line-out/Mic-in interface with high density connector or switch to
high density connector (via software)
– 5 x green lighted, programmable function keys, 2 x for LCD brightness control
– 1 x light sensor on front cover for auto LCD brightness control
– 1 x G-sensor on front cover for G value detection
– 4 x isolated DI & 4 x isolated DO connectors
RF Functions:
– GPS: Built-in uBlox MAX-M8Q GPS module with external antenna in I/O
plate
– NFC: built-in NFC module with internal antenna (Type 2/ISO 15693/ISO
14443A/S50/S70)
– Bluetooth: Built-in Class 2 Bluetooth V4.0 LE, V3.0+HS, V2.1+EDR module
WWAN: LTE module; Sierra wireless MC73xx with SMA type connector
WLAN: Built-in 802.11b/g/n module with SMA type connector
Power Supply:
– Input Voltage 12V/24V option support 9~32 V power design with
ISO7637-2 & SAE J1113 compliant
– 48v option support 18~58V input for specific application (Option)
Mechanical Design:
– Aluminum chassis with Optional to support whole system IP54 by extended
IO cover
– Weight- under 2.2 kg (~4.85 lbs)
– Dimensions (W x H x D) - 255.7 x 161 x 56 mm (10.04" x 6.30" x2.20")
Environmental Specifications:
– Operating Temperature : -30° C ~ 60° C
– Relative Humidity 95% @ 40° C (No condensing)
– Vibration & Shock: MIL-STD-810G (US highway truck), Method 516.5,
– SAE J1455, Class 5M3 according DIN EN 60721-3-5 (Lv.2 100G, 6ms,
shock)
Power Consumption:
Car Battery 12V 24V
Power off mode 2.4 mA 28.8 mW 2.84 mA 68.2 mW
Idle Mode 1.06 A 12.7 W 0.55 A 13.2 W
Burn-in Mode 1.17 A 14.0 W 0.65 A 15.6 W
