3
TREK-570/303 User Manual
1.2
General Specifications
Key features
Automotive grade working temperature range (-30° C to 70° C)
Rich I/O including CAN, LAN, RS-232, RS-485, J1708, isolation 4DI/4DO, Line
out, Mic in, USB, and Video-in
Built-in GSM/GPRS/LTE (support dual SIM Cards)/GNSS/BT and WLAN
Certifications: CE/FCC/e-mark, MIL-SD810F, ISO 7637-2, SAE J1455, SAE
J1113 regulations
Dual independent display/audio output for both driver and passenger
Ignition on/off delay; SW controllable for car power management
Specifications
Dimensions: (W x H x D): 229.6 x 71 x 117.9 mm
Weight: 2 kg
Vehicle power feature:
–
Input voltage: 6 ~ 32 Vdc, support ignition cold crank
–
Supports Ignition on/off
–
Supports low battery shut-down protection threshold (optional)
–
Supports power off event delay
–
Supports power on delay
–
Supports power low delay
–
Supports power low hard delay
–
Supports hard off delay
Note! For more detail of function please refer to Chapter 6, Section 6.3 of this
manual.
CPU: Intel Atom E3826(Dual Core, 1.46GHz)
BIOS: 8MB Flash BIOS, ACPI Compliant.
System memory: One SODIMM sockets, accepts up to 8GB DDR3L1067
SDRAM
Storage: One mSATA slot, support system boot up
Serial ports: Two CAN Bus, 1x FF-RS232
Two 4-wire RS232,1 x RS485, 1 x J1708 ports
Universal serial bus (USB) port: one USB3.0 Type A, one USB 2.0 Type A
LAN port: 1 x 10/100/1000 Ethernet by RJ45
Note! This product is covered by one or more of the following patents:
US5,307,459, US5,434,872, US5,732,094, US6,570,884, US6,115,776
and US6,327,625.
Chapter 1
General Information
