3 TPC-300 Elkhart Lake Series User Manual
Chapter 1 General Information
Power Consumption:
This product is intended to be supplied by a IEC/UL 60950-1/IEC/UL 62368-1-
recognized limited power source that is rated as follows:
– TPC-312 EHL: 39.01 W (typical)
24 VDC, minimum 5A, minimum operating temperature 60 °C/140 °F
– TPC-315 EHL: 30.16 W (typical)
24 VDC, minimum 5A, minimum operating temperature 60 °C/140 °F
– TPC-317 EHL: 40.00 W (typical)
24 VDC, minimum 5A, minimum operating temperature 60 °C/140°F
– TPC-324W EHL: 49.72 W (typical)
24 VDC, minimum 5A, minimum operating temperature 50 °C/122 °F
1.2.2 System Hardware
CPU: Intel
®
Elkhart Lake Atom™ 6525E/ Celeron
®
J6412 processor i
Memory: 4GB DDR4 SODIMM (built-in)
LAN: 2 x 10/100/1000BASE-T
Expansion Slot: 1 x Full-size mini PCIe
Storage Slots:
– 1 x M.2 (B key): 2242/ 2280 (SATA/ USB3.0); 3042/ 3052 (5G)
– 1 x 2.5" SSD/ HDD (SATA, Max. 7mm)
I/O Ports:
– 1 x RS-232
– 1 x RS-232/422/485
– 3 x USB 3.2
– 1 x USB 2.0
– 1 x iDoor slot
– 1 x Displayport (Video output)
– 1 x Audio line out/ mic in
– 1 x Remote Power Buttom
Model Number Processor
TPC-312-RE22A
Intel
®
Atom™ 6425E 2.00 GHz quad core
TPC-315-RE22A
TPC-317-RE22A
TPC-324W-PE22A
TPC-312-RJ22A
Intel
®
Celeron
®
J6412 2.00 GHz quad core
TPC-315-RJ22A
TPC-317-RJ22A
TPC-324W-PJ22A
