SQFlash
SATA DOM 630 Horizontal
Specifications subject to change without notice, contact your sales representatives for the most update information.
REV 1.0 Page 5 of 25 Apr. 1, 2016
2. Features
Standard SATA interface
– Support SATA 1.5 Gbps, 3.0 Gbps, and 6.0 Gbps interface
– SATA Revision 3.0 compliant
– Power management supported
Operating Voltage：5V
Support 72 bit ECC correct per 1K Byte data
TRIM、AHCI supported
Hardware write protect supported
Temperature Ranges
– Commercial Temperature
● 0℃ to 70℃ for operating
● -40℃ to 85℃ for storage
– Industrial Temperature
● -40℃ to 85℃ for operating
● -40℃ to 85℃ for storage
Mechanical Specification
– Shock：1,500G / 0.5ms
– Vibration：20G / 80~2,000Hz
Humidty
– Humidity：5% ~ 95% under 55℃
Endurance : > 2,000,000 program/erase cycles
– This is a test result of the whole SQFlash drive. The test is to keep writing a fixed logical block address (LBA)
and see if any bad blocks occur after 2M cycles. With wear-levelling mechanism, although the disk was kept
writing the same LBA but the physical block changes per block writing. So this test also proves that
wear-leveling is really working, or the block would be wearout after its designated life cycles.
Data Retention
– 10 years
Acquired RoHS、WHQL、CE、FCC Certificate
Acoustic：0 dB
Dimension：44.7 mm x 22.2 mm x 1.0 mm
