15 SOM-DH7000 User Manual
Chapter 3 Connectors and Jumper Settings
3.1.6 Connector List
3.1.7 Jumper, Switch, and Button List
Table 3.2: Connector List
Label Function Label Function
ATX1 ATX connector GPIO1 GPIO pin header
SLOT_12V Slot power connector PCIE_RD_I2C
I2S wafer box for PCIe Re-
driver
LAN0 RJ45 LAN connector PCIE_X1_1~3 PCIe p23-x1 slot
USB3 01~23 USBC 3.2 Gen1 port PCIE_X4_1 PCIe p23-x4 slot
COM0~1
COM Port0~1 connector
(Tx, Rx)
PCIE_X8_1 PCIe p23-x8 slot
QFN_BIOS QFN SPI BIOS socket PCIE_X16_1~4 PCIe x16 slot
SOIC_BIOS1 SOT8 SPI BIOS socket ESPI1 ESPI/LPC pin header
SPI_CN1 SPI BIOS pin header BH1 RTC battery connector
SMB1 SMBus wafer box SMART_FAN1 Smart fan connector
I2C0~1 I2C 0~1 wafer box SYS_FAN1 System fan connector
IPMB1 IPMB wafer box SATA 1~2 SATA port connector
Table 3.3: Jumper, Switch and Button List
Label Function Label Function
J7 COM_HPC type pin 2 SLEEP1 Sleep button
PSON1 ATX / AT mode selection LID1 LID switch
J5
COM_HPC module +V5SB
supply
RAPID1 Rapid shutdown button
J3 +Vcc_Boot_SPI EXT_THRM1
External thermal trip but-
ton
J4 BOOT_SPI_CS chip select WAKE1 Wake button
J6 Clear CMOS SYS_RESET1 Reset button
J8
PCIE_RD_MODE_SE-
LECT
PWRBTN1 Power button
BIOS_SEL0~2 BIOS select 0~2
PWRBTN_PH1 PWRBTN pin header
SYS_RE-
SET_PH1
System reset BTN pin
header
PWR_LED_PH1 Power LED pin header
BATLOW1 BATLOW pin header
TAMPER1 TAMPER pin header
CB_PWROK Carrier board power OK
SMB_ALT1 SMBus alert pin header
