15 SOM-DH5000 User Manual
Chapter 3 Connectors and Jumper Settings
3.1.7 Connector List
Table 3.1: Connector List
Label Function Label Function
ATX1 ATX Connector ATX12V1 DC 12V Input Connector 1
SLOT12V1
DC 12V Input Connector
2
BH1 RTC Battery Socket
BMC_SMB_HDR BMC IPMB Pin Header CN10 GPIO Pin Header
CN9 BMC SPI Pin Header COM2
COM-HPC UART Port 1
Wafer Box
COM3
BMC Debug Console
Wafer Box
COM4
BMC UART Port 1 Wafer
Box
ESPI1 eSPI Debug Pin Header GPSPI_PH1 GP SPI Pin Header
I2C0
COM-HPC I2C Port 0
Wafer Box (3.3V)
I2C1
COM-HPC I2C Port 1 Wafer
Box(1.8V)
J1
COM-HPC Connector (A,
B, C, D)
J2
COM-HPC Connector (E, F,
G, H)
LAN0
COM-HPC NBASE-T Port
0
LAN1_USB23
LAN1, USB 3.0/2.0 Port 2
and Port 3 Connector
M2M1
M.2 M-Key Connector 1
(PCIe Lanes 56-59)
M2M2
M.2 M-Key Connector 2
(PCIe Lane 60-63)
OCP1/OCP2
OCP Module Connector 1
and 2
PCIEX16_1
PCIe x16 Slot (PCIe Lanes
16-31)
PCIEX4_0
PCIe p23-x4 Slot 0 (PCIe
Lanes 12-15)
PCIEX4_1
PCIe p23-x4 Slot 1 (PCIe Lanes
0-3)
PCIEX4_2
PCIe p23-x4 Slot 2 (PCIe
Lanes 4-7)
PCIEX4_3
PCIe p23-x4 Slot 3 (PCIe Lanes
8-11)
PCIEX4_4
PCIe p23-x4 Slot 4 (PCIe
Lanes 48-51)
PCIEX4_5
PCIe p23-x4 Slot 5 (PCIe Lanes
52-55)
PCIEX8_1
PCIe x8 Slot 1 (PCIe
Lanes 32-39)
PCIEX8_2
PCIe x8 Slot 2 (PCIe Lanes
40-47)
PMBUS1 PM Bus Pin Header PWR_LED_PH1
Carrier Board Power Indica-
tor Pin Header
PWRBTN_PH1 Power Button Pin Header SATA1 SATA Port 0 Connector
SATA2 SATA Port 1 Connector SMART_FAN1 Smart Fan Connector
SMB1 SMBus Wafer Box SOIC_BIOS0 SPI0 BIOS Socket
SPI_BMC1 BMC SPI Socket SPI0_CN SPI0 BIOS Pin Header
SPI1_CN SPI1 BIOS Pin Header
SYS_FAN1/
SYS_FAN2
System Fan Connector 1
and 2
SYS_RE-
SET_PH1
System Reset Button Pin
Header
TAMPER1 Tamper Pin Header
USB2_1
USB 2.0 Port 4, 5, 6, and
7
USB3_01
USB 3.0/2.0 Port 0 and Port
1 Connector
VGA_COM1
CRT and COM-HPC
UART Port 0 DB9 Con-
nector
