SOM-DB5830 User Manual iv
Warnings, Cautions, and Notes
Document Feedback
To assist us with improving this manual, we welcome all comments and constructive
criticism. Please send all feedback in writing to support@advantech.com.
Selection Guide
Pin Description
Advantech provides useful checklists regarding schematic design and layout routing.
The schematic checklist provides details about each pin’s electrical properties and
connection method for various usage scenarios. The layout checklist specifies the
layout constraints and recommendations in terms of trace length, impedance, and
other necessary information during the design process.
Contact your nearest Advantech office for design documents and advanced technical
support.
Warning! Warnings indicate conditions that, if not observed, can result in personal
injury!
Caution! Cautions are included to help prevent hardware damage and data
losses. For example,
“Batteries are at risk of exploding if incorrectly installed. Do not attempt
to recharge, force open, or heat the battery. Replace the battery only
with the same or equivalent type as recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.”
Note! Notes provide optional additional information.
Part Number Description
SOM-DB5830-00A1 COM Express R3.0 development board for Type 6 pinout modules
SOM-DB5830-00A2 COM Express R3.0 development board for Type 6 pinout modules
SOM-DB5830-00A3 COM Express R3.1 development board for Type 6 pinout modules
