SOM-7583 User Manual 8
1.3.7.9 Serial port
2 x wire serial port (Tx/Rx) and support 16550 UART compliance:
Programmable FIFO or character mode
16-byte FIFO buffer on transmitter and receiver in FIFO mode
Programmable serial-interface characteristics: 5, 6, 7, or 8-bit character
Even, odd, or no parity bit selectable
1, 1.5, or 2 stop bit selectable
Baud rate up to 115.2K
1.3.7.10 TPM
Support TPM 2.0 module by default.
1.3.7.11 Smart Fan
Support 2 x Fan PWM control signal and 2 x tachometer inputs for fan speed detec-
tion. Provides 1 x on module with connector and 1 x on carrier board followed by
PICMG COM Express R3.0 specification.
1.3.7.12 BIOS
There is a BIOS chip on the module by default. Users can place BIOS chip on a car-
rier board with appropriate design and jumper setting on BIOS_DIS#[1:0].
Notice: We recommend going to the BIOS setup menu and loading the default set-
tings during the first boot up if the system COMS are cleared.
1.3.8 Power Management
1.3.8.1 Power Supply
Supports both ATX and AT power modes. The VSB is for suspend power and is
optional if not required by standby (suspend-to-RAM) support. The RTC Battery is
optional if keeping time and date is not required.
V
CC
: 8.5V ~ 20V
V
SB
: 4.75V ~ 5.25V (Suspend power)
RTC Battery Power: 2.0 ~ 3.3V
1.3.8.2 PWROK
Power OK (PWROK) is from the main power supply. A high value indicates sufficient
power. This signal can be used to delay module startup in order to program the time
of carrier based FPGAs or other configurable devices.
1.3.8.3 Power Sequence
According to PICMG COM Express R3.0 specifications.
BIOS_DIS0# BIOS_DIS#1 Boot up destination/function
Open Open Boot from Module’s SPI BIOS
Open GND SPI_CS0# to Carrier Board, SPI_CS1# to Module
GND GND SPI_CS0# to Module, SPI_CS1# to Carrier Board
