SOM-7532 User Manual 6
1.3.3 Processor System
1.3.4 Memory
Dual channels onboard LPDDR4 3200MT/s up to 16GB, up to 4267MT/s by specific
SPU SKUs. (non-ECC)
1.3.5 Graphics/Audio
Graphics Core: Intel
®
Gen10 UHD/P630 Graphic supports DX12, OGL5.0, OCL2.1,
and MPEG2, HEVC/H265, VC1/WMV9 HW decode/encode/transcode acceleration.
1.3.6 Expansion Interface
1.3.6.1 PCIe p16-x1
PCI Express x1: Supports default 4 ports PCIe p16-x1 compliant to PCIe Gen3 (8.0 GT/s)
specifications, configurable to PCIe x4 or PCIe x2. Several configurable combina-
tions may need BIOS modification. Please contact the Advantech sales or FAE for
more details.
1.3.6.2 LPC
Supports Low Pin Count (LPC) 1.1 specification, without DMA or bus mastering.
Enables connection to Super I/O, embedded controller, or TPM. 24MHz LPC clock.
Table 1.3: Processor System
CPU Std. Freq. Max. Turbo Freq. Core Cache (MB) TDP(W)
Pentium J6426 2.0 GHz 3.0 GHz 4 4 10W
Pentium N6415 1.2 GHz 3.0 GHz 4 4 6.5W
Atom x6211E 1.3 GHz 3.0 GHz 2 4 6W
Atom x6425RE 1.9 GHz - 4 4 12W
Atom x6425E 2.0 GHz 3.0 GHz 4 4 12W
Atom x6413E 1.5 GHz 3.0 GHz 4 4 9W
Table 1.4: Graphics/Audio
CPU Graphic Core Base Freq. Max Freq.
Pentium J6426 Gen10 UHD Graphic 400 850
Pentium N6415 Gen10 UHD Graphic 350 800
Atom x6211E Gen10 UHD Graphic 350 750
Atom x6425RE Gen10 UHD Graphic 400 -
Atom x6425E Gen10 UHD Graphic 500 750
Atom x6413E Gen10 UHD Graphic 500 750
Table 1.5: PCIe x1
Type 10
Row A,B
P0 P1 P2 P3
Default
Config
X1 X1 X1 X1
Option 1 X4
