SOM-6884 User Manual 2
1.1 Introduction
SOM-6884 is designed for high-performance edge computing applications. The new
COM Express Type 6 Compact Module is integrated with a 13th Gen Intel® Core™
processor (formally called Raptor Lake-P). The processor provides fourteen cores of
computing performance with TDP under 45 Watts. It also comes with the excellent
Intel® Iris® Xe graphics, and the Advantech ready-to-use Edge AI Suite software
toolkit. The new SOM-6884 is an ideal solution for medical imaging and AI applica-
tions.
SOM-6884 is designed to support up to 64GB of DDR5 4800 RAM for groundbreak-
ing computing and graphics performance. (That’s 1.5X performance compared to the
previous generation.) In addition, there are numerous ultra-high-speed I/O interfaces
included, such as PCIe Gen4 (16GT/s), 2.5Gbase-T, and USB 3.2 Gen2 (10Gbps),
for plenty of system expansion options. In particular, for USB, there is a reference
design document and development board called SOM-MZ20 to help with USB4
implementation.
The unit has also been developed to easily accommodate four independent displays
of up to 4K resolution. There are three DisplayPort 1.4/HDMI 2.0 and one optional
eDP or LVDS interface. Furthermore, the device can be configured for up to two 8K
HDR outputs. With the optional NVMe SSD, TPM 2.0 on-board design, 8.5~20V
power input feature, and -40 to 85°C operating temperature range (Heat spreader &
QFCS included.), SOM-6884 is a suitable and reliable solution to readily meet edge
computing requirements.
Advantech iManager (SUSI 4) was developed for the requirements of embedded
applications and is equipped with a multi-level watchdog timer, voltage and tempera-
ture monitoring, thermal protection and mitigation through processor throttling, LCD
backlight on/off and brightness control, embedded storage for customized informa-
tion, and more. With Advantech WISE-PaaS/RMM, it can perform remote monitoring
and can control devices through the Internet for easy maintenance. All Advantech
COM Express modules integrate iManager and WISE-PaaS/RMM as an add-on fea-
ture for customer applications.
Capable of solid performance under extreme conditions, and featuring embedded
platform power efficiency and multiple expansion I/O interfaces, SOM-6884 is a prod-
uct that is compute-centric, thermal sensitive, with robust graphics/media capabili-
ties, and well-suited for demanding I/O applications.
1.1.1 Acronyms
Table 1.1: Acronyms
Term Define
AC’97 Audio CODEC (Coder-Decoder)
ACPI
Advanced Configuration Power Interface – standard to implement power sav-
ing modes in PC-AT systems
BIOS
Basic Input/Output System – firmware in the PC-AT system that is used to ini-
tialize system components before handing control over to the operating sys-
tem
CAN
Controller-area network (CAN or CAN-bus) is a vehicle bus standard
designed to allow microcontrollers to communicate with each other within a
vehicle without a host computer.
DDI Digital Display Interface – containing DisplayPort, HDMI/DVI, and SDVO
