SOM-5899Refresh User Manual 20
3.1 Starting
The SOM-5899Refresh BIOS is stored on a flash ROM which can be inserted into a
BIOS socket on the board. Users can modify BIOS settings and control various sys-
tem features with the BIOS Setup program. This chapter describes the basic naviga-
tion of the SOM-5899Refresh BIOS setup screens.
Advantech will have revisions for product optimization so customers can re-flash the
latest BIOS through the AFU utility. Please contact Advantech sales or FAE for more
information.
Entering the BIOS
To enter the BIOS Setup screens, follow the steps below:
1. Power on the motherboard.
2. Press the Delete or Esc key on your keyboard when you see the following text
prompt: Press Delete or Esc to enter setup.
3. After you press the Delete key, the main BIOS Setup menu will appear. You can
access the other BIOS function settings.
The BIOS Setup screen has three main frames. The left frame displays all informa-
tion and configurable items. Grayed-out text is information only. Blue items are
options that can be configured. White text is the item currently selected.
The right-upper frame is an area reserved for a text message. When an option is
selected from the left frame, a help message will show in this area.
The following table shows the hotkey operation guide.
Hotkey Description
ā Right
ā Left
The left and right < > keys allow you to select a BIOS setup page.
For example: Main page, Advanced page, Chipset page, and so on.
