SOM-5899Refresh User Manual 10
1.3.13 Advantech iManager
Supports APIs for GPIO, smart fan control, multi-stage watchdog timer, temperature
sensor, and hardware monitoring. Follows PICMG EAPI 1.0 specifications with back-
ward compatibility.
1.3.14 Power Consumption
Hardware Configurations:
1. MB: SOM-5899RC7Q-U7A1 (PCB: A101-2)
2. DRAM: 16GB DDR4 2666MHz x 3
3. Carrier board: SOM-DB5830 A101-2
Testing Conditions:
1. Test temperature: room temperature (about 25 °C)
2. Test voltage: rated voltage DC +12.0V
3. Test loading:
Maximum load mode: According to Intel thermal/power test tools
Burn-in mode: Burn-in test V8.1 Pro (1023) for 64 bit Windows (CPU, RAM,
2D&3D Graphics and Disk with 100%)
Idle mode: DUT power management off and not running any program
4. OS: Windows 10 Enterprise
1.3.15 Performance
To compare performance or benchmark data with other modules, please refer to
“Advantech COM Performance & Power Consumption Table.”
Power Consumption Table (Watt.)
VCC=12V,
VSB=5V
Active Power Domain Suspend Power Domain
Mechanical
off
Power State S0 Max. Load S0 Burn-in S0 Idle S5 S5 Deep Sleep RTC (uA)
SOM-
5899RC7Q-
U7A1
108.74W 64.704W 8.277W 1.016W 0.418W 6.48uA
