SOM-5894 User Manual 2
1.1 Introduction
SOM-5894 is a COM-Express Basic module with pin-out Type 6 that fully complies
with the PICMG (PCI Industrial Computer Manufactures Group) COM.0 R2.1 specifi-
cation. The CPU module incorporates an Intel 4th Generation Core i processor, PCH
QM87, and other peripheral chips. The latest Intel processor uses 22nm and 3D Tri-
gate transistor technologies that brings 13% performance improvement over previ-
ous versions, and integrates a powerful Intel HD Graphic 4600 as well as DX11.1,
OpenCL1.2, OpenGL4.0 API enabling better display configurations with no band-
width limitations. With Intel PCH QM87, SOM-5894 provides advanced interfaces
such as PCI Express Gen 3, SATA Gen 3, and USB3.0. Moreover, PCIe x16 can be
used in combination of p10-x4 or p10-x8 to make it more flexible.
Advantech iManager 2.0 was invented to satisfy a lot of embedded application
requirements such as multi-level watchdog timer, voltage and temperature monitor-
ing, thermal protection and mitigation through processor throttling, LCD backlight on/
off and brightness control, and embedded storage. Combining Advantech SUSI
Access, it can remotely monitor and control devices via the internet for easy main-
tainance. All Advantech COM Express modules integrate iManager and SUSI Access
to benefit our customer’s applications.
With top performance and lower power consumption, various extensions and I/O
interfaces, SOM-5894 is suitable for computing intensive design, thermal sensitive
design, graphics/media insensitive design, and I/O demanding applications.
1.2 Specifications
1.2.1 Board Information
Pin Definition: PICMG COM.0 R2.1 Type 6 pin-out definition
Form Factor: PICMG COM.0 R2.1 Basic Module 125 x 95 mm
1.2.2 System Information
CPU: 4th Generation Intel® Core Processor
Chipset: Intel® QM87 Express Chipset
Memory: 2 SODIMM Socket for DDR3L-1600/1333, up to 16GB
BIOS: AMI UEFI 128Mbit SPI BIOS
Power management: Supports power saving modes including Normal /
Standby / Suspend modes. ACPI 2.0 compliant
CPU
Standard
Freq. (GHz)
Max.Turbo
Freq. (GHz)
Core
Cache
(MB)
TDP
(W)
i7-4700EQ 2.4 3.4 4 6 47
i5-4400E 2.7 3.3 2 3 37
i5-4402E 1.6 2.7 2 3 25
i3-4100E 2.4 NA 2 3 37
i3-4102E 1.6 NA 2 3 25
Celeron 2000E 2.2 NA 2 2 37
Celeron 2002E 1.5 NA 2 2 25
