SKY-MXM-T1000 User Manual 2
1.1 Introduction
As an NVIDIA Elite Partner, Advantech offers MXM GPU cards powered by NVIDIA’s
embedded GPUs. These are perfect for image processing and Edge AI acceleration
in the manufacturing, medical, and gaming industries. Built on the latest Nvidia archi-
tectures, Advantech MXM GPU provide state-of-the-art technologies which deliver
high-performance computing, responsive system capabilities, and reduced latency —
attributes ideal for deploying auto-optical inspection, driver-assistance, and surgical
system applications.
The Advantech SKY-MXM-T1000 MXM module is a high-performance MXM graphics
module based on NVIDIA T1000 chipsets. It features 896 CUDA cores, 4GB GDDR6,
2.7 TFLOPS Single-Precision Performance, and support for 4 x display port. In addi-
tion, it features a small form factor for easy system integration and provides cool-run-
ning, low-power operation capabilities for embedded applications.
1.2 Features
NVIDIA
®
Quadro
®
T1000 with MXM 3.1 TYPE A form factor (82 x 70 mm)
Up to 896 CUDA cores, 2.7 TFLOPS
GDDR6 4GB memory, 128-bit, bandwidth 192 GB/s
Up to 4 x DisplayPort 1.4a outputs
Long life cycle with 5+ years availability support
1.3 Specifications
1.3.1 Processor System
1.3.2 Memory
Table 1.1: Processor System
GPU
Quadro
®
T1000
Graphic architecture
NVIDIA
®
Turing™ TU117
CUDA parallel-processing cores
896 CUDA
®
cores
GPU base/boost clock 1395 MHZ/1650 MHZ
FP32 performance 2.6 TFLOPS
Table 1.2: Memory
Technology GDDR6 4GB memory
Interface width 128-bit
Bandwidth 195 GB/s
Max Clock 6000 MHz
