RSB-4680 User Manual 42
3.9 Multi-Display
Please set environment in u-boot as below
3.9.1 VGA(edp) and HDMI(4K)
1. VGA is main display, please set in u-boot as below:
2. HDMI is main display, please set in u-boot as below:
3.9.2 HDMI(4K) and LVDS
1. HDMI is main display, please set in u-boot as below:
2. LVDS is main display, please set in u-boot as below:
3.9.3 LVDS and VGA (edp)
1. LVDS is main display, please set in u-boot as below:
2. VGA is main display, please set in u-boot as below:
LVDS optional: lvds-g070vw01 (800*480), vds-g150xgel05 (1024*768), lvds-
g215hvn01 (1920*1080 dual), lvds-p460hvn02 (1920*1080 dual 30bits), lvds-
lmt101dnmfdd (1024*600), lvds-lmt150dngfdd (1024*768)
HDMI optional: hdmi-720p?hdmi-1080p
VGA(edp) optional: edp-1024x768, edp-1920x1080, edp-1920x1200
rkboot # setenv prmry_screen edp-1024x768
rkboot # setenv extend_screen hdmi-720p
Note! This is the default setting.
rkboot # setenv prmry_screen hdmi-720p
rkboot # setenv extend_screen edp-1024x768
rkboot # setenv prmry_screen hdmi-720p
rkboot # setenv extend_screen lvds-g070vw01
rkboot # setenv prmry_screen lvds-g070vw01
rkboot # setenv extend_screen hdmi-720p
rkboot # setenv prmry_screen lvds-g070vw01
rkboot # setenv extend_screen edp-1024x768
rkboot # setenv prmry_screen edp-1024x768
rkboot # setenv extend_screen lvds-g070vw01
