53 RSB-4220 User Manual
Chapter 3 Software Functionality
3.8.3.4 CAN Programming
Refer to <BSP_PATH>/source/demo/can_test.
3.8.3.5 Brightness Programming
Refer to <BSP_PATH>/source/demo/brightness
The brightness driver provides the sys interface. The brightness value can be set and
obtained using the sys file as follows:
/sys/class/backlight/pwm-backlight/brightness
Set the brightness value using the following command:
Obtain the current brightness value using the following command:
Note! “200” refers to GPIO0; thus, 200 - 207 correspond to GPIO0 - GPIO7.
“out” means output.
“1” is the value set to the corresponding GPIO port.
Note! For the CAN data sending sample c code, refer to can_write.c.
For the CAN data receiving sample c code, refer to can_read.c.
# echo “3” > /sys/class/backlight/backlight/brightness
Note! The value should be between 1-8.
# cat /sys/class/backlight/backlight/brightness
