RSB-3720 User Manual 2
1.1 Introduction
Advantech’s RSB-3720 is powered by NXP's i.MX 8M Plus Processor — the first
Cortex®-A53 based SoC integrated with NPU (Neural Processing Unit). It is capable
of providing outstanding Edge AI inference at 2.3 TOPS and delivers excellent perfor-
mance to Object Detection and Image Segmentation applications. RSB-3720 is a
compact 2.5" Single Board Computer that provides advanced I/O and Extension
capabilities using UIO40-Express.
1.1.1 Product Features
Model Name RSB-3720
Form Factor 2.5" UIO40-Express SBC
Processor
System
CPU
NXP i.MX8M Plus Cortex-A53 Dual / Quad core (up to
1.8GHz)
Memory
Technology LPDDR4 4000MT/s
Capacity On-board 4 GB / 6 GB
Flash
16 GB eMMC Flash for O.S. and 8 MB QSPI NOR Flash
for board information
NPU 2.3 TOPS Neural Network performance
Graphics
HDMI 1 x HDMI 2.0a, up to 3840 x 2160 at 30Hz
LVDS
1 x Single Channel or 1 Dual Channel 24 Bit LVDS,
Backlight Power: 5V/12V, Max. 1A
MIPI-DSI
1 x 4-Lane MIPI-DSI (shared with LVDS connector by
BOM option)
Graphics Engine
GC7000UL with 2D/3D Graphic Acceleration supporting
1G Pixel/s, OpenVG 1.1, Open GL ES3.1, Vulkan, and
Open CL 1.2 FP.
H/W Video Codec
Decoder: 1080p60 HEVC/H.265 Main, VP9 Profile 0/2,
VP8, AVC/H.264 Baseline/Main/High Encoder: 1080p60
AVC/H.264, HEVC/H.265
Ethernet
Chipset NXP i.MX8M Plus integrated RGMII
Speed 2 x 10/100/1000 Mbps
WatchDog
Timer
WatchDog Timer 1~6553s, power on/off 4s
TPM TPM 2.0 (ST33HTPH2E32AHB8)
RTC RTC RTC Battery by 2pin type connector
Reset 1 x Reset Button
I/O
USB 1 x USB 3.2 Gen 1 By 1 Host, 1 USB 2.0 Host
Audio 1 x Mic-in / 1 Line-Out by pin header
CAN
1 x CANBus for RSB-3720CD/CQ or 1 CAN-FD for
RSB-3720WD/WQ by COM1 pin header*
Serial Port
1 x 4 wires RS-232/422/485 by pin header* (default con-
figured as debug console)
Camera Input 2 x 4-Lane MIPI-CSI2
Rear I/O UIO40-Express
1 x USB 3.2 Gen1 By 1, 3 x USB 2.0, 10 x GPIO, 2 x
UART, 1 x CANBus, and 1 x I2C
Indicator
LED 1 x Green Power LED
1 x Blue Programmable LED
