11 ROM-DB7501 User Manual
Chapter 2 H/W Installation
Table 2.9: Internal I/O Connector
Position Description Connector Type
USB0 USB port 0 Pin header 2 x 5, 2.54 mm 180D (M) yellow
CN16 PCIe p19-x1 connector 1
PCI Express 36P 180D (F) DIP 2EG01817-
D2D-DF
SATADOM_
PWR1
SATA-DOM jumper (power +5V
pin 7)
Pin header 3 x 1P, 2.0 mm 180D (M) DIP 2000-
13 WS
SATA1 SATA connector
Serial ATA 7P 1.27 mm 180D (M) DIP WATM-
07DBN4A3B8
SATAPWR1 SATA power connector
Wafer 4P 2.5 mm 180D (M) DIP 24W1161-
04S10-01T
COM1 UART1 (RS232, 4 wires)
Box header 5x2P 2.54 mm 180D (M) DIP
23N6960-10S10
CN13 Reserved for EC programming
Box header 5x2P 2.54mm 180D (M) DIP
23N6960-10S10
MODULE1 MXM connector
I2C1 I2C pin header
Wafer box 2.0 mm 4P 180D (M) with lock
A2001WV2-4P
I2S_CN1 Audio codec connector
Pin header 2 x 10P 2.54 mm 180D (M) DIP
21N22564
SPI1 SPI connector 1
Pin header 2 x 4P 2.54 mm 180D (M) SMD
21N22564
SW1 Reset button TACT SW STS-091 SMD 4P H = 3.8 mm
SW2 Sleep button TACT SW STS-091 SMD 4P H = 3.8 mm
SW3 Power button TACT SW STS-091 SMD 4P H = 3.8 mm
LVDS1 LVDS (24 bit)
B/B Conn. 40P 1.25 mm 90D SMD DF13-
40DP-1.25V(91)
LVDS_BK_P
WR1
LVDS backlight power
Wafer box 2.0 mm 5P 180D (M) DIP WO/Pb
JIH VEI
LVDS_BK_P
WR2
LVDS backlight power
Wafer box 2.0 mm 5P 180D (M) DIP WO/Pb
JIH VEI
LVDS_BL2
LVDS backlight selection
(+12V/5V)
Pin header 3 x 1P 2.54 mm 180D (M) DIP 205-
1x3GS
LVDS_BL1
LVDS backlight selection
(+12V/5V)
Pin header 3 x 1P 2.54 mm 180D (M) DIP 205-
1x3GS
LVDS_VDD1
LVDS VDD power selection
(+3.3V/+5V)
Pin header 3 x 1P 2.0 mm 180D (M) DIP 2000-
13 WS
LVDS_VDD2
LVDS VDD power selection2
(+12V)
Pin header 2 x 1P 180D (M) square 2.0 mm
DIP W/O Pb
LVDS_VDD3
LVDS VDD power selection
(+3.3V/+5V)
Pin header 3 x 1P 2.0 mm 180D (M) DIP 2000-
13 WS
LVDS_VDD4
LVDS VDD power selection 2
(+12V)
Pin header 2 x 1P 180D (M) square 2.0 mm
DIP W/O Pb
USB_OTG1 USB OTG Mini USB 5P 180D (F) SMD UH51543-CS7-7F
BAT1 Lithium-ion battery power input
Wafer 8P 2.54 mm 180D (M) DIP A2543WV2-
8P (6 ~ 8.4 V recommended)
BH1 CR-2032 connector
Battery holder 24.9*23.4*8.9 CR2032
BH800.4GG
SD1 SD socket
SD CONN 9P 90D(F) SMD DM1AA-SF-
PEJ(82)
CN18 Power button connector
Pin header 2 x 1P 180D (M) square 2.0 mm
DIP
