ROM-DB5900 A2 User Manual 20
P93 HDMI_D2- S93 LCD_D0
P94 GND S94 LCD_D1
P95 HDMI_D1+ S95 LCD_D2
P96 HDMI_D1- S96 LCD_D3
P97 GND S97 LCD_D4
P98 HDMI_D0+ S98 LCD_D5
P99 HDMI_D0- S99 LCD_D6
P100 GND S100 LCD_D7
P101 HDMI_CK+ S101 GND
P102 HDMI_CK- S102 LCD_D8
P103 GND S103 LCD_D9
P104 HDMI_HPD S104 LCD_D10
P105 HDMI_CTRL_CK S105 LCD_D11
P106 HDMI_CTRL_DAT S106 LCD_D12
P107 HDMI_CEC S107 LCD_D13
P108 GPIO0 S108 LCD_D14
P109 GPIO1 S109 LCD_D15
P110 GPIO2 S110 GND
P111 GPIO3 S111 LCD_D16
P112 GPIO4 S112 LCD_D17
P113 GPIO5 S113 LCD_D18
P114 GPIO6 S114 LCD_D19
P115 GPIO7 S115 LCD_D20
P116 GPIO8 S116 LCD_D21
P117 GPIO9 S117 LCD_D22
P118 GPIO10 S118 LCD_D23
P119 GPIO11 S119 GND
P120 GND S120 LCD_DE
P121 I2C_PM_CK S121 LCD_VS
P122 I2C_PM_DAT S122 LCD_HS
P123 BOOT_SEL0# S123 LCD_PCK
P124 BOOT_SEL1# S124 GND
P125 BOOT_SEL2# S125 LVDS0+
P126 RESET_OUT# S126 LVDS0-
P127 RESET_IN# S127 LCD_BKLT_EN
P128 POWER_BTN# S128 LVDS1+
P129 SER0_TX S129 LVDS1-
P130 SER0_RX S130 GND
P131 SER0_RTS# S131 LVDS2+
P132 SER0_CTS# S132 LVDS2-
P133 GND S133 LCD_VDD_EN
P134 SER1_TX S134 LVDS_CK+
P135 SER1_RX S135 LVDS_CK-
P136 SER2_TX S136 GND
P137 SER2_RX S137 LVDS3+
P138 SER2_RTS# S138 LVDS3-
P139 SER2_CTS# S139 I2C_LCD_CK
Table 2.14: CN41 (CN41A, MXM 3.0 connector)
