ROM-DB5900 A2 User Manual 12
CN14
CAN2 bus, 120om terminal
resistor
PIN HEADER 2*1P 180D(M)SQUARE 2.0mm
DIP W/O Pb
CN15
UART2 selection jumper
(RS232/422/485)
PIN HEADER 9x2P 2.0mm 180D(M) DIP
21N22050-18S10
CN16A UART0 (RS232)
D-SUB Conn. 18P 90D(M) DIP DM10151-
H531-4F
CN16B UART2 (RS232/422/485)
D-SUB Conn. 18P 90D(M) DIP DM10151-
H531-4F
CN17 UART1 (RS232, 2wires)
BOX HEADER 5x2P 2.54mm 180D(M) DIP
23N6960-10S10
CN18 UART3 (RS232, 2wires)
BOX HEADER 5x2P 2.54mm 180D(M) DIP
23N6960-10S10
CN21 SPDIF
PIN HEADER 1X5P 2.54mm 180D 210-91-
05GB01
CN22 Camera 1 connector (MIPI)
B/B CONN. 2x15P 0.5mm 180D(M) SMD DF12
(3.0)-30D
CN23 Camera 2 connector (MIPI)
B/B CONN. 2x15P 0.5mm 180D(M) SMD DF12
(3.0)-30D
CN24
GPIO0 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN25
GPIO9 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN26
GPIO1 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN27
GPIO2 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN28
GPIO3 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN29 Reserved for CAN
PIN HEADER 1X5P 2.54mm 180D 210-91-
05GB01
CN30
GPIO4 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN31
GPIO5 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN32
GPIO6 (Reserved for multi-
function)
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN33 GPIO connector
PIN HEADER 10x2P 2.0mm 180D(M) DIP
21N22050
CN34 GPIO8
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN35 GPIO7
PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-
13 WS
CN37 External WDT out
PIN HEADER 2*1P 180D(M)SQUARE 2.0mm
DIP W/O Pb
CN38 System Fan Wafer 2.54mm 3P 180D(M) DIP 22-27-2031
CN39 AFB
PIN HEADER 2x15P 2.54mm 180D(M)
21N22564-30S10B-
CN40 Reserved for EC programming
BOX HEADER 5x2P 2.54mm 180D(M) DIP
23N6960-10S10
CN41 MXM 3.0 connector
CN42 HDMI connector
HDMI Conn. 19P 0.5mm 90D(F) SMD
QJ51191-LFB4-7F
I2C1 I2C pin header
WAFER BOX 2.0mm 4P 180D(M) W/LOCK
A2001WV2-4P
