ROM-DB5900 A2 User Manual 2
1.1 Introduction
ROM-DB5900 is an evaluation carrier board designed for the Advantech SMARC
module. It is compatible with SMARC module ROM-5420 and has rich I/O interface
for evaluation and development. It supports wide range operating temperatures, 4
power input interfaces (one of them is designed for lithium-ion battery) and also sup-
ports two MIPI connectors for the camera module. ROM-DB5900 is an ideal develop-
ment board for mobile applications, such as portable device, industrial tablet or HMI
systems.
ROM-DB5900 comes with RISC SMARC carrier board design documents: Carrier
Board Design Guide, Layout, Schematic checklist, and also the reference board
schematics ready for you to start your own carrier board design.
2 power inputs. +12V DC-IN and lithium battery
2 camera input support
12 GPIO
4 UART and 2 CAN ports
1.2 Product Specification
Compatible
Module
Advantech SMARC v1.0 & v1.1 CPU Modules
Graphic
HDMI 1 HDMI TypeA
LVDS 1 Dual 24-bit LVDS
TTL 1 20 pins with female connector
Ethernet 10/100/100 Mbps 1 RJ45
Storage
eMMC Onboard 4GB eMMC
EEPROM Onbard 4MB EEPROM
SD 1 SD card slot
SATA 1 SATAII Connector (with SATA-DOM support)
I/O
USB 2 USB 2.0 Type A (Host), 1 min USB Type AB (OTG)
UART 4 UART Ports
Audio 1 1/8 Audio Jack (I2S HD Audio), 1 SPDIF Pin header
CAN 2 CAN 2.0B ports, Differential mode +5V
GPIO 12 GPIO Ports
I2C 2 I2C pin header
SPI 2 SPI pin header
Camera input 2 MIPI connectors
AFB 1 30pin AFB connector
Expansion PCIe slot 3 PCIe x1
Power input Power 2 Power Inputs (+12V DC-Jack, Lithium-ion battery)
Environment
Operation 0~60C (32~140°F)
Operating Humidity 0% ~ 90% relative humidity, non-condensing
Physical
Characteristics
Dimensions 305 x 244 mm (12" x 9.6")
