3 ROM-7421 User Manual
Chapter 1 Product Overview
1.2 Product Features
Compatible Module Qseven 2.0
Processor System CPU
NXP ARM Cortex-A9 i.MX6 Dual/Quad Plus
high performance processor
Memory
Technology DDR3 1066 MHz
Capacity On-board DDR3 512MB/1GB/2GB
Flash
4 GB eMMC for O.S. and 4 MB NOR Flash for
Advantech boot loader
Graphic
Graphics Engine
3 GPUs. OpenGL ES 2.0 for 3D, BitBlt for 2D
and OpenVG 1.1
H/W Video Codec
Decoder: MPEG-4 ASP, H.264 HP, H.263,
MPEG-2 MP, MJPEG BP
Encoder: MPEG-4 SP, H.264 BP, H.263,
MJPEG BP
HDMI 1920 x 1080 at 60Hz
LVDS
2 18/24-bit LVDS, 1366x768 for single chan-
nel, 1920x1080 for dual channel
Ethernet
Chipset NXP i.MX6 integrated RGMII
Speed 1 10/100/1000 Mbps, Max. 400Mbps
Watch Dog Timer
256 Level timer interval, from 0 ~ 128 sec,
multi-option S/W watchdog timer
I/O
PCIe 1 PCIe x 1
SATA 1 SATA II
USB 4 USB 2.0, 1 USB2.0 OTG
Audio I2S
SDIO 8-bit SDIO
Serial Port 2 UART (4 wire)
SPI 1
CAN 1 x CAN bus 2.0B
GPIO 8
I2C 2 I2C
O.S Linux & Android
Power Supply Voltage +5 V
Environment
Operation 0 ~ 60° C/ -40 ~ 85° C
Operating Humidity 5% ~ 95% relative humidity, non-condensing
Physical
Characteristics
Dimensions (WxD) 70 x 70 mm
Camera Input Dimensions (WxD) 1 MIPI v1.0, 4x Lane
