ROM-6881 User Manual 10
2.3 Pin Definition
Please refer to the 314 Pin MXM golden finger following SMARC 2.1 standard pin
definitions as detailed below:
Table 2.5: P-Pin
P-Pin SMARC2.1 I/F ROM-6881 Pin Out
P1 SMB_ALERT_1V8# SMB SMB_ALERT_1V8#
P2 GND POWER GND
P3 CSI1_CK+ SCAM MIPI_CSI1_RX_CLK0P
P4 CSI1_CK- SCAM MIPI_CSI1_RX_CLK0N
P5 GBE1_SDP GBE N/A
P6 GBE0_SDP GBE N/A
P7 CSI1_D0+ SCAM MIPI_CSI1_RX_D0P
P8 CSI1_D0- SCAM MIPI_CSI1_RX_D0N
P9 GND POWER GND
P10 CSI1_D1+ SCAM MIPI_CSI1_RX_D1P
P11 CSI1_D1- SCAM MIPI_CSI1_RX_D1N
P12 GND POWER GND
P13 CSI1_D2+ SCAM MIPI_CSI1_RX_D2P
P14 CSI1_D2- SCAM MIPI_CSI1_RX_D2N
P15 GND POWER GND
P16 CSI1_D3+ SCAM MIPI_CSI1_RX_D3P
P17 CSI1_D3- SCAM MIPI_CSI1_RX_D3N
P18 GND POWER GND
P19 GBE0_MDI3- GBE GBE0_MDI3-
P20 GBE0_MDI3+ GBE GBE0_MDI3+
P21 GBE0_LINK100# GBE GBE0_LINK100#
P22 GBE0_LINK1000# GBE GBE0_LINK1000#
P23 GBE0_MDI2- GBE GBE0_MDI2-
P24 GBE0_MDI2+ GBE GBE0_MDI2+
P25 GBE0_LINK_ACT# GBE GBE0_LINK_ACT#
P26 GBE0_MDI1- GBE GBE0_MDI1-
P27 GBE0_MDI1+ GBE GBE0_MDI1+
P28 GBE0_CTREF GBE N/A
P29 GBE0_MDI0- GBE GBE0_MDI0-
P30 GBE0_MDI0+ GBE GBE0_MDI0+
P31 SPI0_CS1# SPI N/A
P32 GND POWER GND
P33 SDIO_WP SDIO N/A
P34 SDIO_CMD SDIO SDIO_CMD
P35 SDIO_CD# SDIO SDIO_CD#
P36 SDIO_CK SDIO SDIO_CK
P37 SDIO_PWR_EN SDIO SDIO_PWR_EN
P38 GND POWER GND
P39 SDIO_D0 SDIO SDIO_D0
P40 SDIO_D1 SDIO SDIO_D1
P41 SDIO_D2 SDIO SDIO_D2
