Je bekijkt pagina 12 van 74
ROM-6881 User Manual 2
1.1 Introduction
The Advantech ROM-6881 SMARC 2.1 Computer-on-Module is powered by a Rock-
chip RK3588 SoC which includes Quad Arm Cortex-A76 and Quad Cortex-A55 pro-
cessors, 6Tops NPU, and a high-performance Arm Mali-G610 3D graphics engine.
ROM-6881 supports 8K @60fps H.265/VP9 video decoding, and 8K @30fps H.265/
H.264 video encoding. It also provides a rich display interface supported with HDMI,
DP, eDP, and LVDS/MIPI-DSI to meet different display requirements. ROM-6881
offers various high-speed interfaces, including 2 x USB 3.0, 4 x PCIe 3.0, SATA 3.0,
Gigabit Ethernet, CAN, and MIPI-CSI. These interfaces can meet a variety of high-
rate transmission applications, Wi-Fi 6, and wireless 5G connectivity targeted at big
data and other industrial applications.
The ROM-6881 is paired with the Advantech SOM-DB2510 SMARC2.1 development
board for faster end-product peripheral integration and time-to-market. The reference
schematics and layout checklist documentation for carrier board development will be
provided along with the open-source Linux BSP, test utilities, hardware design utili-
ties, and reference drivers.
1.2 Product Features
Table 1.1: Specifications
Form Factor SMARC 2.1 via MXM 3.0 Connector
Processor
System
CPU
Rockchip RK3588 Arm Quad Cortex-A76 2.4GHz
and Quad Cortex-A55 1.8GHz
NPU
Up to 6.0 Tops
Support: TensorFlow, Caffe, Tflite, Pytorch, Onnx
NN, Android NN, etc.
Memory
Capacity Onboard LPDDR4 up to 4/8GB
Flash 32/64 GB eMMC NAND Flash for OS
Graphics
Graphics Engine
Arm Mali-G610 MP4 GPU, High performance
OpenGL ES 1.1, 2.0 and 3.2, OpenCL 2.2, Vul-
kan1.2 etc.
H/W Video Codec
Decoder: H.265/VP9 8K@60fps, H.264
8K@30fps, H.263,VC-1,VP8,MVC,AV1, MPEG-4/
2/1
Encoder: H.265/H.264 8K@30fps, Multi-channel
encoder in parallel for less resolution
Display Display out
1 x Single channel LVDS (default) or 1 x dual
channel LVDS, up to 1920 x 1200 (BOM option)
1 x HDMI 2.1
1 x DP 1.4
1 x eDP
1 x MIPI-DSI (BOM Option, shared with LVDS0)
Ethernet Chipset & Speed 2 x RTL8211FS 10/100/1000 Mbps
RTC RTC Yes
Watch Dog
Timer
Watch Dog Timer
HW watch dog by MCU. 1~6527s, default 60s,
power on/off 1s
