ROM-5720 User Manual 12
P96 HDMI_D1- S97 N/A
P97 GND S98 N/A
P98 HDMI_D0+ S99 N/A
P99 HDMI_D0- S100 N/A
P100 GND S101 GND
P101 HDMI_CK+ S102 N/A
P102 HDMI_CK- S103 N/A
P103 GND S104 N/A
P104 HDMI_HPD S105 N/A
P105 HDMI_CTRL_CK S106 N/A
P106 HDMI_CTRL_DAT S107 N/A
P107 N/A S108 N/A
P108 GPIO0/ CAM0_PWR# S109 N/A
P109 GPIO1/ CAM1_PWR# S110 GND
P110 GPIO2/ CAM0_RST# S111 N/A
P111 GPIO3/ CAM1_RST# S112 N/A
P112 GPIO4 S113 N/A
P113 GPIO5 S114 N/A
P114 GPIO6 S115 N/A
P115 GPIO7 S116 N/A
P116 GPIO8 S117 N/A
P117 GPIO9 S118 N/A
P118 GPIO10 S119 GND
P119 GPIO11 S120 N/A
P120 GND S121 N/A
P121 I²C_PM_CK S122 N/A
P122 I²C_PM_DAT S123 N/A
P123 BOOT_SEL0# S124 GND
P124 BOOT_SEL1# S125 DSI0_D0+
P125 BOOT_SEL2# S126 DSI0_D0-
P126 RESET_OUT# S127 LCD0_BKLT_EN
P127 RESET_IN# S128 DSI0_D1+
P128 POWER_BTN# S129 DSI0_D1-
P129 SER0_TX S130 GND
P130 SER0_RX S131 DSI0_D2+
P131 SER0_RTS# S132 DSI0_D2-
P132 SER0_CTS# S133 LCD0_VDD_EN
P133 GND S134 DSI0_CLK+
P134 SER1_TX S135 DSI0_CLK-
P135 SER1_RX S136 GND
P136 SER2_TX S137 DSI0_D3+
P137 SER2_RX S138 DSI0_D3-
P138 N/A S139 I²C_LCD_CK
P139 N/A S140 I²C_LCD_DAT
P140 SER3_TX S141 LCD0_BKLT_PWM
P141 SER3_RX S142 N/A
P142 GND S143 GND
P143 N/A S144 N/A
P144 N/A S145 WDT_TIME_OUT#
P145 N/A S146 PCIE_WAKE#
P146 N/A S147 VDD_RTC
P147 VDD_IN S148 LID#
