ROM-5720 User Manual 10
3.1 Pin Definition
Please refer to the 314 Pin MXM golden finger following SMARC 2.0/2.1 standard pin
definition as below:
P-Pin Signal S-Pin Signal
S1 I²C_CAM1_CK
P1 SMB_ALERT_1V8# S2 I²C_CAM1_DAT
P2 GND S3 GND
P3 CSI1_CK+ S4 N/A
P4 CSI1_CK- S5 I²C_CAM0_CK
P5 N/A S6 CAM_MCK
P6 N/A S7 I²C_CAM0_DAT
P7 CSI1_RX0+ S8 CSI0_CK+
P8 CSI1_RX0- S9 CSI0_CK-
P9 GND S10 GND
P10 CSI1_RX1+ S11 CSI0_RX0+
P11 CSI1_RX1- S12 CSI0_RX0-
P12 GND S13 GND
P13 CSI1_RX2+ S14 CSI0_RX1+
P14 CSI1_RX2- S15 CSI0_RX1-
P15 GND S16 GND
P16 CSI1_RX3+ S17 GBE1_MDI0+
P17 CSI1_RX3- S18 GBE1_MDI0-
P18 GND S19 GBE1_LINK100#
P19 GBE0_MDI3- S20 GBE1_MDI1+
P20 GBE0_MDI3+ S21 GBE1_MDI1-
P21 GBE0_LINK100# S22 GBE1_LINK1000#
P22 GBE0_LINK1000# S23 GBE1_MDI2+
P23 GBE0_MDI2- S24 GBE1_MDI2-
P24 GBE0_MDI2+ S25 GND
P25 GBE0_LINK_ACT# S26 GBE1_MDI3+
P26 GBE0_MDI1- S27 GBE1_MDI3-
P27 GBE0_MDI1+ S28 N/A
P28 N/A S29 N/A
P29 GBE_MDI0- S30 N/A
P30 GBE_MDI0+ S31 GBE1_LINK_ACT#
P31 N/A S32 N/A
P32 GND S33 N/A
P33 SDIO_WP S34 GND
P34 SDIO_CMD S35 USB4+
P35 SDIO_CD# S36 USB4-
P36 SDIO_CK S37 N/A
P37 SDIO_PWR_EN S38 AUDIO_MCK
P38 GND S39 I2S0_LRCK
P39 SDIO_D0 S40 I2S0_SDOUT
P40 SDIO_D1 S41 I2S0_SDIN
P41 SDIO_D2 S42 I2S0_CK
P42 SDIO_D3 S43 N/A
P43 SPI0_CS0# S44 N/A
P44 SPI0_CK S45 N/A
