ROM-5720 User Manual 2
1.1 Introduction
ROM-5720 SMARC2.0/2.1 Module leverages NXP i.MX8M Arm® Cortex®-A53 high-
performance processors to support a Vivante GC7000 Lite 3D Graphics engine and
4Kp60 HEVC decoding with HDR.
ROM-5720 is equipped with an Advantech ROM-DB5901 Evaluator Carrier Board for
easy integration and reference. Advantech also offers referenced schematics and
layout checklists for carrier board development. Additionally, Linux BSP, test utilities,
HW design utilities and reference codes are ready for application development and
device integration.
ROM-5720 is suitable for following applications:
Computer Vision
Medical Applications
Robotic Applications
Infotainment Applications
Portable Devices
1.2 Product Features
Compatible
Module
SMARC 2.0 & SMARC 2.1 compliance
Processor
System
CPU
NXP Arm® Cortex®-A53 i.MX8M Dual/Quad, up to
1.5GHz
Memory
Technology LPDDR4 1866 MHz
Capacity On-board 2 GB
Flash 16 GB eMMC for O.S. and 8 MB NOR Flash
Graphic
H/W Video
Decode
HEVC/H.265(4Kp60), VP9(4Kp60), H.264(4Kp30), MPEG-
2, MPEG-4p2, VC-1, VP8, RV9, AVS, MJPEG, H.263
HDMI 4096 x 2160 at 60 Hz
MIPI-DSI
1 x 4-lane MIPI DSI, up to 1920 x 1080 @ 60Hz
Camera Input MIPI-CSI 1 x 4-lane MIPI CSI, 1 x 2-lane MIPI CSI
Ethernet
Transceiver
NXP i.MX8M GbE controller Integrated RGMII
1 x RTL8119I-CG Giga LAN controller
Speed 2 x 10/100/1000 Mbps
Watch Dog
Timer
HW WDT MSP430 (time out: 0.1~6553.5s, power on/off 4s)
I/O
USB 2 x USB 3.0, 4 x USB 2.0 Host, 1 x USB 2.0 OTG,
I2S 2
SDIO 1
UART 1 x UART w/ 4wires, 3 x UART w/ 2wires,
SPI 1
GPIO 12
I²C 4
PCIE 1 x PCIe2.0 1-lane
O.S Linux Yocto
Dimensions W x D
82 x 50 mm
(3.34 x 1.96 in)
Power DC-In
Fixed 5V DC source and allow 3.3 V ~ 5.25 V operates
directly from single level Lithium Ion cells
