3 ROM-5620 User Manual
Chapter 1 General Introduction
1.3 Mechanical Specifications
Dimensions: SMARC form factor size: (D x W) 82 x 50 mm / 3.22 x 1.96 in
Height on Top: Under 3.0 mm (0.11 in) base on SPEC definition (without heat
sink)
Height on Bottom: Under 1.3 mm (.051 in) base on SPEC definition
I/O
PCIe 1 x PCIe 3.0
SATA -
USB 1 x USB 3.0, 1 x USB 2.0 Host, 1 x USB 2.0 OTG
Audio 2 x I2S
SPDIF -
SDIO 1
Serial Port 1 x 4-wire UART and 2 x 2-wire UART
SPI 2
CAN 2 CANBus 2.0 A/B
GPIO 12 GPIO Ports
I2C 4 with interrupt
Camera Input 1 x 4-Lane MIPI-CSI2
System Bus -
Touch -
Keypad -
Power
Power Supply Voltage 4.75~5.25V
Power Consumption 4.45W (Max)
Environment
Operating Temperature 0 ~ 60 °C / -40 ~ 85 °C (32 ~ 140 °F / -40 ~ 185 °F)
Operating Humidity 5% ~ 90% relative humidity, non-condensing
Mechanical Dimensions (W x D) 82 x 50 mm (3.22 x 1.96 in)
Operation System Linux & Android
Certifications CE/FCC Class B
